KPS by Power Probe KPS DCM7000BT Digital Clamp Meter

Features and Benefits:

• The DCM7000BT is a versatile clamp meter designed for accurate electrical measurements. With its TRMS capability; it ensures precise readings in various scenarios. The meter offers a high-resolution display with 6000 counts; allowing for accurate AC measurements. It can measure AC current up to 600A and AC/DC low currents down to 4000?A; covering a wide range of current applications. Voltage measurements are also comprehensive; with the ability to measure up to 1000V AC and 1000V DC. The meter supports resistance measurements up to 600k? and frequency measurements up to 10kHz.Other useful features include the ability to perform continuity tests and diode tests; ensuring efficient circuit checks. The meter can also measure capacitance up to 1000?F and incorporates a non-contact voltage detection feature for added safety. It offers convenient data hold; relative measurements; and MIN/MAX value tracking functions. The meter's auto-ranging capability simplifies the measurement process; and the 37mm jaw size allows for easy clamping on various conductors. The auto-off feature conserves battery life; while the backlight display ensures readability in low-light environments. Connectivity options such as Bluetooth and data logging further enhance the functionality of this clamp meter. With its CAT III 1000V and CAT IV 600V safety ratings; the DCM7000BT provides reliable and secure measurements in diverse electrical applications.



TRMS; 6;000 count with large white LED backlight display; DC 600mV measurement for sensors or other applications; DC uA for flame rod testing; Min/Max Hold; Data Logging/Manual Save up to 4;000 records; Inrush Current measurement (100ms); Special designed LoZ (Low Impedance) feature to prevent false reading caused by ghost voltages
