MAHLE Service Solutions 15 Ton Air Lift and Support Stand

Features and Benefits:

• Designed for spring; tire; and brake work on agricultural sprayers and equipment
• 100% air operated
• Built-in vehicle support stand equipment
• Multiple width saddle options included
• Removable handle
• Can be used in pairs with the air valve T-connector
• Capacity 30;000 lb (13;608 kg)
• Minimum Start Height 17.6 in (45 cm)
• Maximum Lift Height w/ Extension 52.3 in (133 cm)
• Maximum Lift Height w/o Extension 37.3 in (95 cm)
• Cylinder Bore 14 in (36 cm)
• Required Air Pressure 200 psi (13.8 bar)
• Overall Length w/ Handle 58.5 in (149 cm)
• Overall Length w/o Handle 25.5 in (65 cm)
• Wheel Diameter 5 in (13 cm)
• Stroke 10 in (25 cm)
• Inside Saddle Width 4.8 in (12 cm)
• Overall Saddle Width 5.5 in (14 cm)
• Extension Tubes Square
• Handle Length 36.5 in (93 cm)
• Shipping Weight 230 lb (104 kg)



ShopPRO air lifts offer an easy-to-use air rocker valve that provides smooth and precise raising and lowering control. The perfect solution for spring work.
