Rotary R145DR Tiltback VSC Tire Changer

Features and Benefits:

• Comes standard with metal and plastic mounting and demounting heads.
• EXCLUSIVE VARIABLE SPEED CONTROL INVERTER:
• Rotary's innovative inverter regulates rotational speed by slowing as the stress on the bead increases avoiding any damage to the tire. The double-acting bead breaker cylinder is designed to work on low-profile and large-sized steel or alloy rims.
• Center Post Locking System;
• The center-clamp design drastically reduces risk of wheel damage and the restrictions of turntables with clamping jaws. Works with reverse rims.
• Quick Locking Wheel Center Adapter
• Plastic & Steel Mount / Demount Heads Included
• Lower bead lifting roller rolls the bottom bead off on wide tires helping lift large tires to remove the bottom beads.
• Pneumatic Top Bead Pressing Tool helps mount low profile and run flat tires without using extra bars and people.
• Hand controlled side bead breaker increases control of breaking hard beads. No stretching around large tires to reach a pedal.
• Integrated wheel lift
• Rim clamping 10"" to 30""
• Maximum rim width 15""
• Maximum tire diameter 47""
• Maximum bead breaker opening 15""
• Bead breaker cylinder power at 145 psi 6;745 lbs.
• Recommended air supply 11-145 psi; 8-10 bar
• Power dupply 220 volts; 10 amps; 60 hz



High volume design and productivity features make this the go to pro performance swing arm tire changer for the busiest tire centers. Easy to use center post mounting head and tire lever increase productivity and reduce the risk of wheel dame.
